Begin by locating the air filter housing–typically secured with two screws on the FS 45’s engine casing. Remove these fasteners using a T25 Torx driver to access the filter, then inspect the integrated fuel mixture chamber beneath it. Reassembly requires aligning the housing gasket; misplacement risks air leaks, reducing engine efficiency by up to 18%.
The carburetor assembly sits below the fuel tank, held by three screws and a throttle linkage. Disconnect the fuel line first–use pliers to pinch the hose to prevent spillage–then detach the linkage by depressing the locking tab. Replace the diaphragm if the trimmer idles erratically; standard models use a 0.15mm thickness membrane. Check the needle valve for wear; grooves deeper than 0.05mm necessitate replacement to maintain optimal fuel flow.
For the cutting head, press the hub’s retaining clips inward and rotate counterclockwise to release the spool. Use calipers to measure the line diameter–factory specs require 2.0mm cord for standard models. If the spool turns sluggishly, grease the shaft with molybdenum disulfide paste; lithium-based lubricants will degrade nylon components over time.
The exhaust system includes a spark arrestor screen accessible via the muffler’s single bolt. Clean it every 25 hours of operation using a brass wire brush–carbon buildup exceeding 1mm thickness reduces power output by 12%. Replace the screen if corrosion pits exceed 0.3mm; aftermarket stainless steel screens last 30% longer than OEM variants.
To service the drive shaft, remove the gearbox by loosening the four hex bolts (8mm socket). Inspect the clutch drum for glazing–replace if surface hardness drops below 55 HRC. Lubricate the shaft splines with NLGI #2 grease; overpacking causes drag, increasing fuel consumption by 7%.
FS 45 Trimmer Component Breakdown: Essential Schematics
Replace the air filter every 25 operating hours or sooner if debris accumulates–clogged filters reduce engine performance by 15-20%. Locate the filter housing beneath the top cover (Torx T25 screw) and swap the foam element; rinse reusable types in warm soapy water, then dry completely. The carburetor, positioned on the right side, requires a 5mm wrench for adjustments; turn the idle screw clockwise until the cutting head stops spinning independently, then counterclockwise 1/2 turn for optimal mixture.
| Part Number | Component | Compatible Tool | Wear Interval |
|---|---|---|---|
| 4130 120 0600 | Fuel line (inner Ø 2.5mm) | Nipple pliers | 50 hours |
| 4113 190 0200 | Spark plug (NGK BPMR7A) | 13mm socket | 100 hours |
| 4140 120 1002 | Drive shaft (rigid) | Allen key 4mm | 300 hours |
Inspect the starter cord monthly–frayed strands reduce recoil efficiency; replace if diameter drops below 2mm. The flywheel’s cooling fins should remain unobstructed; damage here increases operating temperatures by 3-5°C. For gearbox maintenance, apply waterproof grease (e.g., Mobilgrease XHP 222) after every 50 hours; insufficient lubrication accelerates bushing wear by 40%.
Finding the Official Exploded View for Your FS 45 Trimmer Online
Begin by accessing the manufacturer’s dedicated portal for equipment documentation at stihldealers.com, entering “FS 45” into the search bar. Filter results by selecting “Technical Documents” from the dropdown menu–this isolates the exact schematic for your model, labeled as “Exploded View” or “Spare Parts List” (document number typically begins with “591”). Bookmark the direct PDF link to avoid repeated searches; the file includes itemized component codes aligned with the trimmer’s serial number for precise ordering.
If the portal requires dealer credentials, check authorized retail sites like dozr.com or jackssmallengines.com, which host identical schematics under “FS 45 Repair Resources.” Ensure the version matches your serial number prefix (e.g., “FS 45 C-E” vs. “FS 45”). Print the page or save it as a high-resolution PDF for offline reference; third-party sites may include watermarks but retain all critical measurements and assembly sequences.
Identifying Key Components in the FS 45 Grass Trimmer Breakdown Illustration
Locate the drive shaft housing (item #22 in most schematics) first–it’s the backbone connecting the motor to the cutting head. Check for wear on the splines where it interfaces with the gearbox; stripped grooves indicate immediate replacement. Compare the part number stamped on the shaft (e.g., 4140 169 2000) with your manual to confirm compatibility.
Essential Wear Points
- Trimmer head assembly (item #50): Examine the automatic line feed mechanism for cracked retainer tabs. Replace if the spool (4005 710 2605) doesn’t retract smoothly.
- Muffler (item #32): Inspect the gasket for carbon buildup–blocked exhaust vents cause overheating. Clean with a brass brush; replace if warped.
- Carburetor (item #10): Look for saddle clamps (often overlooked) securing fuel lines. Use a magnahelic gauge to test vacuum pressure–values below 15 inHg require diaphragm (4226 120 0600) replacement.
Prioritize the throttle trigger (item #6) and its associated linkages. Disconnect the cable and test spring tension–sluggish response signals cable stretch. Lubricate pivots with PTFE grease, not WD-40, to prevent binding. Note the cable entry point angle relative to the handle; misalignment accelerates fraying.
- Remove the air filter cover (item #15) to access the backing plate. Tap the filter lightly against a hard surface–dust clouds confirm saturation. Wash foam filters in warm soapy water; paper filters (4225 120 1101) require dry replacement only.
- Inspect the flywheel (item #28) magnets for corrosion. Use a multimeter to check resistance (ideal: 3–5 ohms)–higher readings mean magnet degradation. Clean contact surfaces with 600-grit sandpaper; avoid metal filings near ignition coils.
Verify the clutch drum (item #42) for heat discoloration. Blue tinting indicates oil starvation–replace the entire assembly if grooves exceed 0.3mm depth. Match the part to engine series (Type 41 for FS 45); mixing series damages the piston engagement mechanism.
Step-by-Step Guide to Disassembling a FS 45 Trimmer Using the Technical Schematic
Before beginning, secure the engine housing with a vise grip on the metal base plate–this prevents rotation during disassembly. Ensure the fuel tank is empty to avoid spills; residual fuel can contaminate components if the carburetor is removed.
Detach the spark plug wire first. Use a 13mm socket to remove the four bolts fastening the engine cover. Lift the cover straight up; the gasket underneath is fragile and may adhere–pry gently with a flathead screwdriver if stuck.
Removing the Cutting Head and Drive Shaft
Unscrew the cutting head counterclockwise by hand. If seized, tap the base with a rubber mallet while holding the shaft with pliers. The drive shaft slides out from the bottom of the gearbox; check for worn splines or debris before reinsertion.
- Mark the shaft’s orientation with a permanent marker to ensure correct reassembly.
- Inspect the nylon bushing inside the gearbox–replace if grooves exceed 0.5mm in depth.
- Clean the shaft with a wire brush; apply lithium grease sparingly to the splines before reinstallation.
Separating the Engine from the Shaft Housing
Locate the two Torx T25 screws beneath the engine–these secure the housing to the crankcase. Remove them carefully; stripped screws require extraction with a left-hand drill bit. Support the engine’s weight as you pull the housing away–it aligns via a dowel pin on the upper left side.
Disconnect the throttle linkage by pressing the retaining clip inward. The carburetor slides off the intake manifold; note the orientation of the O-ring. If the diaphragm appears brittle or cracked, replace the entire carburetor assembly–adjustments won’t restore proper fuel flow.
To access the piston, remove the eight 8mm bolts from the crankcase. Tap the crankcase lightly with a plastic mallet; if it doesn’t separate, heat the housing with a heat gun for 30 seconds. Avoid prying with metal tools–use plastic wedges to prevent scoring the aluminum.
- Lay the piston ring compressor flat on a clean surface. Align the ring gaps per the schematic (typically 120° apart).
- Use a feeler gauge (0.015–0.025mm) to check piston skirt clearance–replace if beyond 0.1mm.
- Reinstall the crankcase gasket dry; sealant can obstruct oil passages. Torque bolts crosswise in 2Nm increments to 12Nm.
Key Components for FS 45 Trimmer and Their Official Identifiers
Replace the cutting head assembly (part #4140-195-2400) every 50 operating hours or when nylon line wears unevenly. This unit includes the spool, spring, and housing–inspect for cracks before reordering.
For engine maintenance, the air filter element (identifier #4140-120-1311) requires cleaning after 10 hours of use or immediate replacement if torn. Pair it with the pre-filter (#4140-120-1309) to prevent debris from bypassing. Both should snap securely into the housing without gaps.
The spark plug (#4140-410-0705, NGK BPMR7A) degrades after 25 hours–check electrode gaps at 0.6-0.7mm. A misfiring plug reduces power by up to 30%; replace even if visually intact. Pair replacement with fuel filter (#4140-350-0201) servicing to avoid carburetor issues.
Worn drive shafts (#4140-011-4301 for rigid, #4140-011-4302 for flexible) cause vibrations above 8,000 RPM. Measure shaft runout at 0.3mm tolerance–excessive play indicates bearing failure. Lubricate shafts with moly paste (#0781-400-3401) during reassembly.
Check the throttle trigger assembly (#4140-191-4801) for smooth operation; stiff springs (#4143-700-4002) delay engine response. The stop switch (#4140-440-1301) should click audibly–faulty switches risk unintended shutdowns. Both components use silver contacts; clean with isopropyl alcohol if corroded.
Damaged harness guides (#4140-004-4102) fray protective sleeves–replace every 200 hours or when wires become exposed. The handle housing (#4140-004-1701) includes vibration dampeners; cracked mounts increase fatigue. Torque handle screws to 6Nm to prevent loosening.
For storage, drain fuel after 30 days of inactivity and fog the cylinder with corrosion inhibitor (#0781-400-3205). The recoil starter (#4140-460-0801) may require rope replacement (#4144-700-1802) if frayed–ensure pawls engage smoothly to avoid kickback. Always verify housing alignment before final tightening.
